Warm White LED Square Courtesy Lamp
HELLA LED Square Courtesy Lamps are an attractive, energy efficient lamp for interior and exterior use, which can be installed almost anywhere on your truck, bus, van, trailer or camper.
Each lamp is completely sealed, highly shock, impact and vibration resistant, perfectly suited for a demanding environment.
Advanced lens technology provides an even spread of soft light without glare or eye strain. HELLA LED courtesy lamps consume a fraction of the energy of traditional bulb lamps and run very cool due to their low current draw of less than 0.5W (less than 0.04A @ 12V). This provides safer installation into light weight materials where the heat of incandescent lamps may cause damage to the surrounding structure.
Attractive, energy efficient lighting for interior and exterior use, additional surface mounting accessories provide numerous installation options with surface finishes to compliment or contrast the lamp rims. HELLA LED courtesy lamps represent ultra reliable, energy efficient, ‘fit and forget’ technology.
Optic appears clear until illuminated.
Additional trims and spacers are available as spare parts.
RFCommSafe™ - To view and download more information please click here
To find a HELLA reseller near you, click here.
Rollover/tap the icons below for further details:
Fit and Forget
Fit and Forget by Design means every aspect, material and component of this lamp has been carefully chosen to ensure longevity in the most demanding environmental conditions.
LED Technology
RFCommSafe™
RFCommSafe™ products were developed in recognition that some radio communication equipment can be very sensitive in remote areas. RFCommSafe™ products are designed to ensure no interference with any other electronic equipment.
12 Volt
Suitable only for 12VDC applications.
24 Volt
Suitable only for 24VDC applications.
Corrosion Proof
UV Resistant
HELLA New Zealand LED lamps are designed to withstand harsh environmental conditions and will tolerate long term exposure to high UV levels without fading or embrittlement.
5 Year Warranty
This LED based lighting product carries a 5-year warranty covering faults in materials, components or workmanship. Please refer to HELLA’s full terms and conditions.
Dimmable Analogue DC Input
Light intensity is reduced as the DC input voltage is reduced below the lamps specified operating voltage.
Made in New Zealand
Options
Specifications
Lens material |
UV resistant enhanced impact acrylic |
Rim Material |
UV resistant plastic |
Dimming |
Dimmed via Hella marine Dimmer 5XA 998 572-001 |
Cable |
Pre-wired with 120mm of single core marine cable |
Operating Voltage |
12V DC or 24V DC |
Power Consumption |
< 0.5W ( < 0.042A @ 12V / < 0.02A @ 24V ) |
Degree of Protection |
IP 67 - Completely Sealed |
Mounting |
Stainless steel screws included |
Weight |
50g (including cable) |
